GMAC 5 User Guide 25
6.3 SEC protocol alarms
Table 8: SEC protocol alarms
NO. NAME DESCRIPTION
1
Temperature fault
Over temperature in the UPS
2
AC input failure
Input ac voltage failure
3 Output bad Output voltage fault
4
Overload current
Overload
5 Bypass bad Bypass input ac voltage fault
6
No AC output to load
No ac voltage to the load
7
UPS shutdown
The UPS is shutdown
8 Charger failure Charger (rectifier) fault
9 System off The entire UPS system is off
10 Fan failure Fan fault
11
Fuse failure
Fuse fault
12 General fault General fault (enabled when at least one alarm is present)
13
Awaiting power
UPS is awaiting for input power to startup
14 Shutdown pending Shutdown is pending
15 Shutdown imminent Shutdown is imminent
16
On battery
The UPS is drawing power from battery
17 Low battery Battery power is critically low
18
Battery depleted
Battery is depleted
19 On bypass Output source is on bypass
20 Test in progress A test is in progress
21
Battery bad
UPS battery requires replacement
22 Diagnostic test failed Fault in diagnostic self test
23
Test completed
Test completed
24 UPS off as requested The UPS has been turned off by request
25
Output off as requested
The UPS’s output voltage has been switched off by request.
6.4 Megatec protocol alarms
Table 9: Megatec protocol alarms
NO. NAME DESCRIPTION
1 Ac input failure Input ac voltage failure
2 General fault General fault (enabled when at least one alarm is present)
3 Shutdown imminent Shutdown is imminent
4
Low battery
Battery power is critically low
5
On bypass
Output source is on bypass
6 Test in progress A test is in progress
7 Boost or buck is active Input voltage correction is active
