6.6 1UDC+ protocol alarms
Table 11: 1UDC+ protocol alarms
NUMBER NAME DESCRIPTION
1
AC voltage high
Ac input voltage exceeds maximum settings
2 AC voltage low Ac input voltage is lower than minimum
3 DC voltage extremely low Dc voltage exceptionally low – Boost (equalizing) or floating
4
DC voltage low
Dc voltage below minimum – Boost (equalizing) or floating
5 DC voltage high Dc voltage exceeds maximum – Boost (equalizing) or floating
6
Battery breaker open
Battery circuit breaker is OPEN
7
Over temperature
Battery temperature exceeds maximum
8
Battery test failed
Last battery test failed (non-volatile message)
9 LVD driven open Battery LVD is OPEN
10 User dry contact open User volt-free contact is open (NC)
11
Rectifier(s) comm. fault
Communication with rectifier(s) – No response
12 LVD1 driven open LVD number 1 forced OPEN command issued
13
LVD2 driven open
LVD number 2 forced OPEN command issued
14
Load breaker open
One or more load circuit breakers are open
15 Not used alarm 15 N.A.
16
Surge bad
Input ac surge protector reports fault condition
17 Battery test in progress Battery test time-stamp
18
Equalizing in progress
Equalize test time-stamp
19 DC voltage extremely high Dc voltage exceptionally high
20 Overload Overload
21
Not used alarm 21
N.A.
22 Not used alarm 22 N.A.
23
Not used alarm 23
N.A.
24
Not used alarm 24
N.A.
25
Not used alarm 25
N.A.
26 Converter(s) comms. fault Communication with converter(s) – No response
27 Converter high voltage Converter high voltage
28
Converter low voltage
Converter low voltage
29 More than one rect. fault More than one rectifier fault
30
Not used alarm 30
N.A.
31
Startup time stamp
Controller time-stamp
32 Not used alarm 32 N.A.
