6.5 Power+ protocol alarms
Table 10: PowerPlus protocol alarms
NUMBER NAME DESCRIPTION
More than 1 UPS Module is sending an alarm or fault warning
Single UPS Module is sending an alarm or fault warning
3
More than 1 master
encountered
N.A.
4 Output voltage discrepancy N.A.
Load is now running on bypass
Alarm(s) vibrating (alarm is frequently raised and lowered)
8 No AC output to load No ac output to load
9 High battery voltage Excessive battery voltage
11 End of backup End of battery backup. Battery is discharged to shutdown limit
13 Static switch warning Static Switch warning or alarm
14
Emergency Power Off
Emergency Power Off is active
15 Not used alarm 15 N.A.
Batteries failed last test
17 User 1 input open User 1 input volt-free contact open (NC)
18 User 2 input open User 2 input volt-free contact open (NC)
User 3 input volt-free contact open (NC)
20 Input brownout Momentary input ac voltage failure
Ac input voltage is too high
22 AC input failure Ac input failure
Static Switch is not responding
Last controller self-test failed
25 Battery CB is open Battery circuit breaker is open
26
sharing
Possible current sharing fault
27
Suspect a fault output
Possible fault (no current) in 1 or more module output stage
28 UPS shutdown UPS is shutdown
29 Load current high Overload
30
UPS or more not
One or more modules not responding
31 Startup time-stamp Startup time-stamp, indicates controller startup, always present
32 User 4 input open User 4 input volt-free contact open (NC)
