12. POWER
+
PREMIUM 60 SPECIFICATIONS
Table 6: System technical specifications
P
REMIUM
M
ODEL
15 kW
30 kW
45 kW
60 kW
Architecture
Topology
True online battery, double conversion, VFI
Construction
Modular parallel hot-plugged modules
Operation
Continuous
Input
Nominal voltage (Vac)
3×400 (4 wires + Gnd)
Voltage range (%)
–22 / +15
Maximum current (A)
3×27 per module – no inrush current at startup
Frequency (Hz)
47 ~ 63
Power walk-in (s)
1 to 30 in 1 s intervals
Power factor correction
0.99
THDI (%)
<5 %
Inrush current
None
Output
Rated power (kVA/kW)
15/15
30/30
45/45
60/60
Nominal voltage (Vac)
3x400 (4 wires + Gnd)
Frequency, in free-running mode (Hz)
50/60 ±0.1 %
Frequency tracking range (Hz)
±0.5, ±1, ±2, ±3, ±4 (selectable)
Frequency tracking slew rate (Hz/sec)
1.
Static regulation (%)
±1
Regulation for unbalanced load (%)
±1 for 100 % unbalanced load
Dynamic response to 100 % load step (%)
±2
Overload withstand
Inverter mode
110 % : 10 minutes, 125 % : 60 seconds
Bypass mode
125 % : 10 minutes, 1000 % : 1 cycle
Waveform
Sinusoidal
THD (%)
Linear load: <2; non-linear load: <6
Load CF (max)
6:1
Ac-Ac efficiency, nominal (%)
Up to 96
Dc-Ac efficiency, nominal (%)
Up to 98
Batteries
Dc-Link Voltage (Vdc)
±320 to ±405
Quantity and type
60 × 12 Vdc, sealed, lead acid, rechargeable
General
Maximum power dissipation (Po=15 kW)
625 W =
2133 BTU/hr
1250 W =
4266 BTU/hr
1875 W =
6399 BTU/hr
2500 W =
8532 BTU/hr
Fuse clearance capability
Input, output, dc link
Ambient temperature (°C)
-10 to +40 (operating), -20 to +60 (storage)
Relative humidity (%)
95 maximum, non-condensing
Altitude (m)
1500 without derating
Enclosure
IP20
Cooling system
Forced air: multi-fan with speed control
Standards
Safety IEC 62040-1
EMC
IEC 62040-2
Design IEC 62040-3
Low magnetic field radiation EMF as per ICNIRP
Dimensions
Weight of single power module (kg)
10.5
Linear measurements (mm)
797 (H, with wheels, 767 w/o wheels) x 542 (W) x 696 (D)
Weight (kg)
68.5
79
89.5
100
Battery box dimensions (mm): 985 (H) x 540 (W) x 743 (D); weight (empty): 66 kg
All specifications are subject to change without advance notice.
