4
Figure 1: Front View
Install the antenna: The antenna is placed in the accessory
slot of the package box. Please screw the antenna into the
mounting base on the top of the camera and securely tighten it
(Figure 1).
The camera provides the following connections for external
devices: Type-C USB port and DC power slot etc. (Figure 2).
IR LEDs
Lock
Hole
Optics
Lens
Central
PIR Lens
Light
Sensor
Indicator
Lock
Buckle
Antenna
Side
PIR Lens
Side
PIR Lens
