PART #4521777 (08/18/09)
GARLAND CLAMSHELL GRILLS WITH PRODUCT RECOGNITION INSTALLATION/OPERATION MANUAL
Page 11
SPECIFICATIONS
Input Speci cations, GAS Grills, North America:
ELECTRICAL INPUT
(1) 30-AMP
CIRCUIT &
INTERLOCK
TOTAL
kW
LOAD
LOADING: (kW/PHASE) NOMINAL AMPS PER LINE
NEMA
RECEPTACLE
REQUIRED
208V / 220V / 240V 208V / 60Hz 220V / 60Hz 240V / 60Hz
L1/L2 L1/L3 L2/L3 L1 L2 L3 L1 L2 L3 L1 L2 L3
INPUT 1 10.0 3.25 3.25 3.25 28.0 28.0 28.0 26.3 26.3 26.3 24.0 24.0 24.0 15-30R
INTERLOCK HVAC Hood / Fire Suppression Interlock Circuit: 7 Amps / 120V / Single Phase L21-20R
GAS INPUT
GAS
MAX INPUT
NET PER
BURNER
BTU/H
TOTAL INPUT
RATING
BTU/H
INJECTOR
SIZE
AIR SHUTTER
SETTING
MM
SUPPLY
PRESSURE
IN W.C.
BURNER
MANIFOLD
PRESSURE
IN W.C.
NATURAL GAS 32,000 96,000 #35 4.8 3.5 3.5
PROPANE 32,000 96,000 #43 4.8 3.5 10.0
Input Speci cations, GAS Grills, CE Approved Model MWG3W-CE:
ELECTRICAL INPUT
3N~ 400V
50Hz
TOTAL kW
LOAD
LOADING: (kW/PHASE) NOMINAL AMPS PER LINE
MENNEKES
PLUG REQUIRED
L1/L2 L1/L3 L2/L3 L1 L2 L3
10.0 3.25 3.25 3.25 14.1 14.1 14.1 Type 748
GAS INPUT
GAS GROUP
MAX INPUT
NET PER
BURNER kW
TOTAL INPUT
RATING kW
INJECTOR
SIZE
AIR SHUTTER
SETTING mm
SUPPLY
PRESSURE
mbar
BURNER
PRESSURE
mbar
VOLUMETRIC
GAS RATE
G20 NG 8.9 26.7 2.79mm (#35) 4.8 20/25 8.7 0.940 m
3
/h
G25 NG 2.79mm (#35) 4.8 20 8.7
G31 LPG 8.9 26.7 2.26mm (#43) 4.8 37/50 8.7 0.69 kg/h
NET HEATING VALUE BY GAS GROUP
G20 G25 G31
34.02 MJ/m
3
; 0.555 SG 29.25 MJ/m
3
; 0.613 SG 88.0 MJ/m
3
(46.34 MJ/kg); 1.55 SG
GAS CATEGORIES
CATEGORY DESTINATION COUNTRIES SUPPLY PRESSURE (mbar)
I
2H
AT, CH, CZ, DK, ES, FI, GB, IE, IS, IT, NO, PT, SE 20.0
I
2E
DE, LU 20.0
I
2L
NL 25.0
I
2ER
FR 20.0 / 25.0
I
3P
NL 30.0
I
3P
BE, CH, CZ, ES, FR, GB, GR, IE, LU 37.0
I
3P
BE, CH, DE, CZ, ES, FR, NL 50.0
