Garland XPE24 Service Manual

Document: GAR_SM_4601777 (4/16) 21
Section 1 General Information
XPE-36 1L Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
Cord
1
200V 25.8 23.6 26.5 8.0
208V 25.6 23.3 26.2 8.1
220V 24.1 22.0 23.7 7.9
230V 23.5 21.2 22.6 7.9
240V 23.4 21.0 22.5 7.9
3
Platen
Cord
2
200V 25.8 40.0 37.8 10.6
208V 25.6 39.6 37.5 10.8
220V 24.1 36.8 35.5 10.4
230V 23.5 35.7 35.1 10.5
240V 23.4 35.4 34.8 10.5
XPE-36 2L Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
Cord
1
200V 13.9 16.8 25.8 5.3
208V 14.0 16.5 25.6 5.4
220V 13.8 15.2 24.1 5.2
230V 13.8 14.6 23.5 5.3
240V 13.8 14.6 23.4 5.3
3
Platen
Cord
2
200V 51.6 48.7 49.4 16.0
208V 50.8 48.1 48.4 16.2
220V 46.8 45.1 44.6 15.8
230V 44.9 43.9 42.8 15.9
240V 44.5 43.0 42.3 15.9
XPE-36 1R Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
Cord
1
200V 23.6 26.5 25.8 8.0
208V 23.3 26.2 25.6 8.1
220V 22.0 23.7 24.1 7.9
230V 21.2 22.6 23.5 7.9
240V 21.0 22.5 23.4 7.9
3
Platen
Cord
2
200V 40.0 37.8 25.8 10.6
208V 39.6 37.5 25.6 10.8
220V 36.8 35.5 24.1 10.4
230V 35.7 35.1 23.5 10.5
240V 35.4 34.8 23.4 10.5
XPE-36 2R Models (electric models)
Model
Volts
3Ɏ(WYE)
50/60Hz
Total Current (A)
Power(kW)
L1 L2 L3
3
Platen
Cord
1
200V 25.8 13.9 16.8 5.3
208V 25.6 14.0 16.5 5.4
220V 24.1 13.8 15.2 5.2
230V 23.5 13.8 14.6 5.3
240V 23.4 13.8 14.6 5.3
3
Platen
Cord
2
200V 49.4 51.6 48.7 16.0
208V 48.4 50.8 48.1 16.2
220V 44.6 46.8 45.1 15.8
230V 42.8 44.9 43.9 15.9
240V 42.3 44.5 43.0 15.9
Electrical Input Specification - DELTA (electric XPE-36models)
