Page 5-114 Cirrus Perspective™ Line Maintenance Manual
Rev. E 190-00920-00
5.18 BACKSHELLCONNECTORS
Thefollowingfiguresshowthebackshellconnectors(viewedwiththeLRUremoved).

123
16 17
45678910
11
12131415
1819 2021222324 2526 2728 2930
31323334 353637 38394041 424344
1234567
8
91011121314151617181920
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59
60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78
1 2 3 4 5 6 7 8 91011121314151617181920
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59
60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78
COM BOARD CONNECTOR (P601)
COM ANTENNA CONNECTOR
COOLING PORT
MAIN DISCRETE CONNECTOR (P604)
MAIN SERIAL CONNECTOR (P603)
GPS ANTENNA CONNECTOR
I/O CONNECTOR #2 (P606) I/O CONNECTOR #1 (P605)
G/S ANTENNA CONNECTOR
NAV ANTENNA CONNECTOR
VOR/ILS CONNECTOR (P602)


Figure5‐26.GIA63WBackshellConnectors
