Cirrus Perspective™ Line Maintenance Manual Page 8-3
190-00920-00 Rev. E
•
‘GMA1Fail’alertgiven.
• ‘TrafficFail’alertgiven(ifequipped).
• RedAFCSstatusannunciationgiven(ifequipped).
• TAWSFAILannunciationgiven(ifequipped).
• ADF/DMEwindowsflaginvalid(ifequipped).
8.3 DISPLAYTESTING
Engagetheautopilot(ifequipped)bypressingtheAPkeyontheMFD.
8.3.1 MFDDisplayTestProcedure
1. RemovepowerfromtheMFD.Checkfordesiredresults.Restorepower.
2. ThefollowingshalloccurwhenpowerisremovedfromtheMFD:
• PFDswitchestoreversionmode.
• AFCSdoesnotdisconnect(ifequipped).
• AttitudeandHeadingremainvalidfromAHRS.
• Airspeed,Altitude,VerticalSpeed,andOATremainvalidfromAirData
Computer.
• ValidEngineInstrumentationappearsonPFD.
• XPDRfieldremainsvalidonPFD.
• COM2/NAV2fieldsflaginvalid.
• NAV2CDIdeviationbarisremoved.
• ADF/DMEwindowsflaginvalid(ifequipped).
• ‘GDL69Fail’alertisgiven(ifequipped).
• XTALKERRORalertisgiven.
8.3.2 PFDDisplayTestProcedure
1. RemovepowerfromthePFD.Checkfordesiredresults.
2. Restorepower.
3. ThefollowingshalloccurwhenpowerisremovedfromthePFD:
• MFDswitchestoreversionmode.
• AttitudeandHeadingremainvalidfromAHRS.
• Airspeed,Altitude,VerticalSpeed,andOATremainvalidfromAirDataComputer.
• MFDretainsengineinstrumentation.
• ValidXPDRfieldappearsonMFD.
• COM1/NAV1fieldsflaginvalid.
