Garmin GMR FANTOM Series User Manual

Specifications
Specification Measurement
Weight
Pedestal: 15.8kg (34.8lb.)
4ft. antenna: 5.2kg (11.4lb.)
6ft. antenna: 7.3kg (16.0lb.)
Operating temperature range From -15 to 55°C (from 5 to 131°F)
Transmitter center frequency From 9335 to 9455MHz
Power cable length 15m (49ft. 3in.)
Network cable length 15m (49ft. 3in.)
Antenna rotation speed 24rpm and 48rpm
1
Maximum wind load 80kn
Humidity 95% at 35°C (95°F)
Water rating IEC 60529 IPX6 (protected against heavy seas)
Bearing accuracy 0.25degrees
Input voltage From 10 to 32Vdc
Power consumption
2
GMR Fantom 54/56:
• Typical: 65W
• Maximum: 170W
GMR Fantom 124/126:
• Typical: 80W
• Max.: 185W
GMR Fantom 254/256:
• Typical: 150W
• Max.: 260W
Fuse
Without voltage converter: 15 A, blade-type
With voltage converter (if applicable): 30A, blade-type
Compass-safe distance 30 cm (11.8 in.)
1
The antenna can rotate at 48rpm only when in single range mode, with MotionScope
™
disabled, and for range settings of 12nmi or lower.
2
Power consumption when transmitting is affected by the range setting. A greater range setting uses more power.
12

Garmin GMR FANTOM Series Specifications

General

Range	Up to 72 nautical miles
Antenna Size	4 ft
Radar Type	Solid State
Rotation Speed	24 RPM standard, 48 RPM high speed
Display Compatibility	Garmin chartplotters
