System at a Glance
Color Conventions
Red
• Warning conditions
Yellow
• Cautionary conditions
Green
• Safe operating conditions
• Engaged modes
• Active COM frequency
White
• Scales and markings
• Current data and values
• Heading legs
Magenta
• GPS data
• Active flight plan legs
• Parallel track
Cyan
• Pilot-selectable references
• Standby COM frequency
Gray
• Missing or expired data
• Product unavailable
Blue
• Water

Garmin GPS 175 Specifications

General

Display Resolution	480 x 272 pixels
GPS Receiver	WAAS GPS
Receiver Type	GPS/WAAS
Display Type	Color TFT
Mounting	Panel mount
Interfaces	RS-232, ARINC 429
Operating Temperature	-20°C to +55°C
Type	Aviation GPS Navigator
Interface	RS-232
Database	Obstacle, Terrain
Compatibility	Compatible with select autopilots
