Garmin GPS 175 User Manual

190-02488-01 Rev. B Pilot’s Guide 2-53
Get Started
Unit Selections
SPECIFY UNIT TYPE
1. Review the current unit selections.
2. Tap the applicable parameter key.
3. Select a unit type.
PARAMETER SETTINGS
Distance/Speed
• Nautical Miles (nm/kt)
• Statute Miles (sm/mph)
Temperature
• Celsius (ºC)
• Fahrenheit (ºF)
NAV Angle
• Magnetic (º)
• True (ºT)
• User (ºU)
Magnetic
Variation
• Specify number of degrees for east or west (ºE, ºW)
• Available only when “User (ºU)” is the active
NAV angle
Customize the display unit settings. Tapping a parameter key
opens a menu of the available unit types.

Garmin GPS 175 Specifications

General

Display Resolution	480 x 272 pixels
GPS Receiver	WAAS GPS
Receiver Type	GPS/WAAS
Display Type	Color TFT
Mounting	Panel mount
Interfaces	RS-232, ARINC 429
Operating Temperature	-20°C to +55°C
Type	Aviation GPS Navigator
Interface	RS-232
Database	Obstacle, Terrain
Compatibility	Compatible with select autopilots
