GPS 500 Pilot’s Guide and Reference
6-8
SECTION 6
WPT PAGES
6.4 AIRPORT FREQUENCY PAGE
The Airport Frequency Page displays radio frequencies
and frequency types for the selected airport, as well as
sector and altitude restrictions (where applicable). If
the selected airport has a localizer-based approach,
the localizer frequency(ies) is also listed on the Airport
Frequency Page (Figure 6-13).
To view frequency information for a particular airport
on the Airport Frequency Page, enter the Airport’s
Identier per Section 6.1.
Figure 6-13 Airport Frequency Page
Scroll
Bar
Usage
Restrictions
Information
Number of Pages in
Current Page Group
Position of
Current Page
within Current
Page Group
Current
Page Group
Airport Identifier,
Symbol, and Type
Frequency
Frequency
Type
Scrolling through the frequency list:
1) Press the small right knob to activate the
cursor.
2) Turn the large right knob to scroll through the
list (Figure 6-14). If there are more frequencies
in the list than can be displayed on the screen,
a scroll bar (Figure 6-13) along the right-hand
side of the screen indicates the cursor’s position
within the list.
Figure 6-14 111.55 Highlighted
Some listed frequencies may include designations for
limited usage, as follows:
• ‘TX’ - Transmit only
• ‘RX’ - Receive only
• ‘PT’ - Part time frequency
190-00181-60 Rev. G
