GPS 500 Pilot’s Guide and Reference
3-1
SECTION 3
DIRECT-TO NAVIGATION
190-00181-60 Rev. G
SECTION 3: DIRECT-TO
NAVIGATION
3.1 OVERVIEW
The GPS 500’s direct-to function provides a quick
method of setting a course to a destination waypoint. Once
a direct-to is activated, the GPS 500 establishes a point-to-
point course line (great circle) from the present position to
the selected direct-to destination. Navigation data on the
various NAV pages provides steering guidance until the
direct-to is cancelled or replaced by a new destination.
Selecting a direct-to destination:
1) Press the Direct-to Key. The Select Direct-to
Waypoint Page appears (Figure 3-1), with the
waypoint identifier field highlighted.
Figure 3-1 Select Direct-to Waypoint Page
2) Use the small and large right knobs to
enter the identifier of the desired destination
waypoint (Figure 3-2).
Figure 3-2 Waypoint Identifier Field Selected
3) Press the ENT Key to confirm the selected
waypoint, and press the ENT Key again to
activate the direct-to function (Figure 3-3).
Figure 3-3 ‘Activate?’ Field Highlighted
When off course while navigating to a waypoint, the
direct-to function may also be used to re-center the CDI
(HSI) needle and proceed to the same waypoint.
Re-centering the CDI (HSI) needle to the
same destination waypoint:
Press the Direct-to Key, followed by the ENT
Key twice.
NOTE: When navigating an approach with the
missed approach point (MAP) as the current
destination, re-centering the CDI (HSI) needle
with the Direct-to Key cancels the approach.
