Garmin GPSMAP 162 - Product Specifications; Physical and Performance Specifications

81
Appendix F
Specifi cations
Physical Specifi cations
Size: 4.63" H x 6.0" W x 2.75" D (11.7cm x 15.2cm x 7cm)
Weight: 1 lb. 6 oz. (.763 kg)
Display: 4.2" diagonal (10.7cm) high-contrast, 4-level gray LCD with backlighting (240 x
240 pixels)
Case: Fully gasketed, high-impact plastic alloy, waterproof to IEC 529-IPX-7
Temp. Range: 5°F to 158°F (-15°C to 70°C)
Performance
Receiver: Differential-ready 12 parallel channel receiver tracks all satellites in view
Acquisition Times:
Warm: Approx. 15 seconds
Cold: Approx. 45 seconds
AutoLocate: Approx. 5 minutes
Update Rate: 1/second, continuous
Accuracy:
Position*: 15 meters (49 feet) RMS; 1-5 meters (3-15 feet) RMS with optional GARMIN
DGPS receiver
Velocity: 0.1 knot RMS steady state
Dynamics: 6g's
* Subject to accuracy degradation to 100m 2DRMS under the U.S. DOD-imposed Selective Availability
Program.
Power
Source: 10-40V DC
Usage: 4 watts max.
Fuse: AGC/3AG - 1.5 Amp
