APPENDIX
Specifications
Physical Specifications
Size: 5.7'' W x 3.2'' H x 1.9'' D
(14.5 x 8.1 x 4.8 cm)
Weight: 13.6 oz (.39 kg)
Display: 3.75'' diagonal (9.5 cm) Transflective, 256-color
display with backlighting (480 x 320 pixels)
Case: Fully gasketed, high-impact plastic alloy,
waterproof to IEC 60529 IPX7
Temp. Range: 5°F to 140°F (-15°C to 60°C)
Power
Battery: Rechargeable lithium-ion
Battery Life: 4 to 15 hours based on backlight usage
Source: 11–35 VDC
Fuse: 3AG-1.5 Amp
Performance
Receiver: Differential-ready 12 parallel channel receiver
Acquisition Times: Approx. 15 seconds (warm start)
Approx. 45 seconds (cold start)
Approx. 5 minutes (First Time/AutoLocate
®
)
Update Rate: 1/second, continuous
Accuracy
GPS: 15 meters (49 feet) RMS 95% typical
DGPS (USCG): 3–5 meters (10–16 ft), 95% typical
DGPS (WAAS): < 3 meters (10 ft) 95% typical with DGPS
corrections
Velocity: 0.1 knot RMS steady state
Dynamics: 6 g's
132 GPSMAP 296 Pilot’s Guide
APPENDIX > SPECIFICATIONS
