GPSMAP
®
4000/5000 Series Owner’s Manual 7
Charts and 3D Chart Views
3. Complete an action:
• For the GPSMAP 4000 series, use the  to pan the map.
• For the GPSMAP 5000 series, touch and drag the Navigation screen to pan the map.
When you pan past the edge of the map, the screen scrolls forward to provide continuous map coverage.
The position icon ( ) stays at your present location. If the position icon leaves the map when you pan, a
small window (inset map) appears on the left of the screen so you can keep track of your present position.
The coordinate location of the cursor appears in the upper-left corner of the map, along with the distance
and bearing of the cursor from your present location.
➌
➍
➎
➋
➊
\
➊
Cursor coordinates
➋
Cursor distance and bearing from present location
➌
Cursor
➍
Inset map
➎
Pan options
4. Select to stop panning and return the screen to your present location.
Showing an Inset Map
You can control whether an inset map appears on the Navigation Chart or the Fishing Chart.
: The Fishing Chart is available with a preprogrammed BlueChart g2 or BlueChart g2 Vision data card,
or by updating to the most current built-in map.
1. From the Home screen, select .
2. Select  , or .
3. Select  >  > .
4. Complete an action:
• Select  to show an inset map at all times.
• Select  to never show an inset map.
• Select  to show an inset map while panning, only when the position icon ( ) is no longer
visible on the screen.
Conguring the Appearance of Waypoint Symbols
1. From the Home screen, select .
2. Select , , or .
3. Select  >  > .
4. Select a waypoint symbol.
