Instructions for users / Charging e-vehiclesInstructions for users / Charging e-vehicles
D
(figure 21)
(figure 22)
INSTRUCTIONS FOR USERS
Charging e-vehicles
1. Connect the wallbox to the vehicle using the cable.
2. Charging commenced, blue light indicates charging in progress.
3. Stop charging. As a rule, the wallbox socket and vehicle inlet lock the cable. As a
result, charging must be stopped before the cable is removed from the vehicle.
4. When charging is completed, ensure the cable has been hung up.
If your wallbox is equipped with a socket, it is important to use the right type of cable. For
example, to charge at 32A, a 32A cable is required.
The status of the wallbox can be obtained from the colour of the Indication light:
• Constant green light: charging can commence.
• Blue pulsating light: charging in progress.
• Red/yellow light: fault. Refer to section on Troubleshooting.
