Gate Titan User Manual

75
Basic Module contents:
1. TITAN V2 NGRS with BASIC rmware edition (rear or front wired)
2. Installation Kit
3. Quickstart Guide
Notice
TITAN V2 NGRS supports:
Tokyo Marui M4 Next Generation
Tokyo Marui SCAR-H Next Generation
Tokyo Marui SCAR-L Next Generation
Tokyo Marui HK416D Next Generation
Tokyo Marui HK416C Next Generation
Tokyo Marui HK417 Next Generation
Caution
TITAN V2 NGRS does not support:
Tokyo Marui 36C Custom Next Generation
Tokyo Marui Model 36K Next Generation
Tokyo Marui AKS74N Next Generation
Tokyo Marui AKS74U Next Generation
Tokyo Marui AK102 Next Generation
Tokyo Marui AK47 Type 3 Next Generation
8.3. Installation safety
Warning
If you use recoil system and set too high trigger sensitivity, it might
cause accidental shooting even without pressing the trigger.
Warning
Pay attention to correctly solder positive and negative TITAN wires to
the connector. Otherwise, aer plugging the battery, the reverse battery
polarity will cause immediate damage to the device. Is not covered by the
warranty and it can lead to re, burn or even battery explosion.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
