Gate Titan User Manual

77
Caution
The improper placement of wiring under motor gear can cause insulation
damage and a short circuit. In order to secure the wires properly we recommend
to perform a gearbox modication as shown in the photos below.
Notice
The selector plate requires modication. Place the selector sticker according
to the photos below. The sticker position is very important.
Notice
In case of TITAN V2 NGRS pre-cocking setup via re selector is
dierent than in case of TITAN V2, due to presence of mechanical
trigger safety lever. In order to set the pre-cocking:
1. Switch re selector to SEMI, re the shot and keep the trigger pulled.
2. While the trigger is pulled you are able to select pre-cocking mode:
• SEMI = Pre-cocking OFF
• AUTO = Pre-cocking AUTO
Setting pre-cocking mode to ‘TRIGGER’ option can be done only via GCS.

Gate Titan Specifications

General

MOSFET	Yes
Battery protection	Yes
Trigger sensitivity adjustment	Yes
Pre-cocking	Yes
ROF control	Yes
Active brake	Yes
Diagnostic system	Yes
Programmable	Yes
Cycle Detection	Yes
Compatibility	V2 Gearbox
Low current consumption in sleep mode	0.2mA
Connectivity	USB-Link, Blu-Link
Fire Modes	Semi, Burst
Bluetooth support	Yes
