13
Replacing the 802.11 Mini PCI card
www.gateway.com
Replacing the 802.11 Mini PCI card
Tools you need to complete this task:
To replace the 802.11 Mini PCI card:
1 Disconnect the power cord, remove the main and optional secondary
battery, and prepare your notebook by following the instructions in
“Preparing your work space” on page 3.
2 Turn your notebook over so that the bottom is facing up.
3 Loosen the captive screw that secures the Mini PCI cover. (The screw
cannot be removed.)
Phillips #0 screwdriver
Mini PCI
cover
