33
Replacing the LCD panel assembly
www.gateway.com
Replacing the LCD panel assembly
Tools you need to complete this task:
Screws removed during this task:
To replace the LCD panel assembly:
1 Disconnect the power cord, remove the main and optional secondary
battery, and prepare your notebook by following the instructions in
“Preparing your work space” on page 3.
2 If your notebook has 802.11 wireless networking built in, remove the
802.11 Mini PCI module by following the instructions in “Replacing the
802.11 Mini PCI card” on page 13.
3 Remove the keyboard cover by following the instructions in “Replacing
the keyboard cover” on page 24.
4 Remove the hinge covers by following the instructions in “Replacing the
hinge covers” on page 31.
Flat-blade screwdriverPhillips #0 screwdriver
4 or 6 chrome 2.5 × 7 mm
(LCD panel hinges)
4 chrome 2.5×5mm
(hinge covers)
