23
Replacing the hard drive in the hard drive kit
www.gateway.com
5 Insert the new drive into the bracket so the screw holes line up, then
replace the four screws that secure the drive to the bracket.
6 Place the new hard drive kit into the drive bay, then slide the drive onto
the connector.
7 Replace the cover and tighten the screw.
Screw
Screw
Screw
Screw
Bracket
To Next Page
