27
Replacing the keyboard
www.gateway.com
3 Remove the five screws that secure the keyboard to your notebook.
4 Lift the back edge of the keyboard slightly, then carefully slide the keyboard
back until the four tabs on the front edge of the keyboard are free from
their slots. Be careful not to damage the LCD panel.
Important There may be a grounding strap attached to the far-right
screw. Make sure this strap is free from the keyboard
before continuing.
Screws
To Next Page
