www.jp.gateway.com
105
電線
アンテナを電灯や電力回路のそば、または電線や電力回路に触れる恐れのある場所に設置しないよう
にしてください。
警告
外部アンテナの取り付け・取り外しの際は、電線や回路に触れないように特
に注意する必要があります。電線や回路に触れると死亡する恐れがあります。
上図の番号 接地コンポーネン
1
電気作業ボックス
2
接地極システム (NEC 250 項、第 H )
3
接地クランプ
4
接地線 (NEC セクション 810-21)
5
アンテナ放電ユニット (NEC セクション 810-20)
6
接地クランプ
7
アンテナ引込み線
2
1
5
3
7
6
4
アンテナと衛星の接地
