CHAPTER 1: Using Your Gateway Flat-Panel Monitor
30
Specifications
Specifications are subject to change without notice or obligation. Many products for Gateway
and its subsidiaries are custom engineered by our suppliers to Gateway specifications and may
vary from similarly marketed products.
Panel size
24 inches (diagonal)
Panel type
24-inch viewable
TFT active matrix S-PVA
Anti-glare coating
Pixel resolution
1920 × 1200 (native) (60 Hz)
Pixel pitch
0.0106 × 0.0106 inches (0.270 mm × 0.270 mm)
Aspect ratio
16:10
Brightness
500 cd/m
2
Contrast ratio
1000:1 (typical)
Viewing angles
176° horizontal, 176° vertical
Response time
8ms (typical)
Frequency
Horizontal: 74 KHz
Vertical: 60 Hz
Lamp type/life
50,000 hours (minimum)
Colors
16.7 million
OSD languages
English, French, Spanish, Italian, Japanese
Connections and inputs
■
Analog (VGA): 15-pin mini d-sub VGA
■
Digital (DVI-D): 24-pin DVD-D (supports 480p, 720p, and 1080i).
Includes HDCP (High-bandwidth Digital Content Protection)
■
Composite video
■
S-Video
■
Component Y Pb Pr (supports 480i, 480p, 720p, and 1080i) (two sets
of component ports for Component 1 and Component 2 inputs)
■
AC power input
■
USB 2.0 B-type (input)
■
USB 2.0 A-type (output ×4)
■
12V/2A speaker bar power output
Included cables
15-pin mini d-sub analog VGA (right-angle)
DVI cable (right-angle)
USB A-B
Power (right-angle)
Power consumption
Normal operation: <125 W
Standby mode: <5 W
Off: <2 W
Power input
100~240 VAC, 50/60 Hz (built-in power supply)
Certifications
UL, cUL, FCC Class B, CE, PSE, NOM, VCCI, TCO’99
Wall mount bracket
VESA 4 3.937 inches (4 100 mm)
Weight
Net weight (with stand): 16.41 lbs. (9 kg)
With stand and optional speaker bar: 17.32 lbs (9.5 kg)
Dimensions
22.24 × 17.02~22.15 × 15.37 inches (564.8 × 432.3~562.7 × 390.3 mm)
