GAUI X4 - Page 14

7
GAUI
TAI SHIH HOBBY CORPORATION
Landing gear assembly
腳架組裝
GAUI
TAI SHIH HOBBY CORPORATION
Tail support rod assembly
支撐桿組裝
螺絲均需上止滑劑
All screws on side plates should
be applied with thread lock.
M3x3........................x2
M3x6........................x1
M3x3........................x2
M3x6........................x1
螺絲均需上止滑劑
All screws on side plates should
be applied with thread lock.
M3x3
M3x3
M3x3
M3x6
M3x6
M3x25
M3x25
M3x10
M3x10
M3x3
M3x25......................x1
M3x25......................x1
M3x10.......................x2
12
12
