Chapter III - Mechanical Overview
Please take some time to familiarize yourself with this section regarding the mechanical overview
of the LaserPro X252RX & X380RX. References will be made back to the different parts of the
LaserPro X252RX & X380RX in later sections.
3.1 Front View
3.2 Top View
SmartEXT™
Pass-Through
Door (Front)
Air Assist Valve
Emergency
Stop
Button
Control Panel
Laser Key Switch
