8.2.2.2 Lubrication of the X / Y Rails
In order to keep the motion system running smoothly, the X / Y rails of the motion system will need
lubrication on a weekly basis. Use a small amount of light grade machine grease to a paper or cotton
towel and apply to the rails.
8.2 Cleaning the Optics System
8.2.1 Removing the Mirrors
We recommend you check the mirrors once or twice a week to see if they require cleaning. If any
debris or smoke residue is present, use the following steps to clean them.
NOTE
• It is highly recommended you remove, clean and replace each mirror one at a
time!
•
Refer to section 8.2.2 on how to clean the mirrors.
The following section will detail how to access and remove each of the four mirrors found on the
LaserPro X252RX & X380RX for cleaning.
Mirror 1
This mirror is located inside the laser cabinet of the LaserPro X252RX & X380RX.
1) Use a #2 Phillips Screwdriver to open the rear laser cabinet of the LaserPro X252RX &
X380RX.
2) Loosen the thumbscrew and remove the dust cover securing the mirror. (As shown in the
picture below).
NOTE
• Always clean and lubricate the rails after working with materials that produce lots of
debris (such as wood).
• Too much oil applied to the X / Y rails will accelerate the build up of debris.
