2. Connect the other end of the audio cable into the input labeled “4x AES In (Digital 8 ch)”
on the Dolby DMA8.
3.2.5 Dolby CP650 Sound Processor
The Dolby CP650 requires an optional board to be used (650-OPTIO-AES). Once installed the
optional 650 OPTIO-AES board will enable 25-pin D-Sub digital input to the Dolby CP650.
To install the board, insert it into the Option I/O Connection on the back of the CP650. Please
refer to the Dolby CP650 manual for more information on installing the 650-OPTIO-AES board.
The board will have two connectors. The one at the top will be the 4xAES connector (this
connector emulates the 4xAES connector on the DMA8).
1. Connect one end of the 25 pin D-Sub audio cable to the audio output on the server.
2. Connect the other end of the audio cable to the top 4xAES connector on the OPTIO-AES
board on CP650.
