GASMAX/TX Operation & Maintenance Manual, Revision 1.0
Page 20
Figure 6-2: GASMAX/TX with Dual Sensors
The GASMAX/TX also supports remote sensors located up to 15 feet from the GASMAX/TX display. Figure
6-3 shows the Sensor Separation Kit required for each remote sensor.
Figure 6-3: P/N 10-0411 Remote Sensor Separation Kit
Dual Local Sensors with “Y” Adapter
GASMAX/TX with Local and Remote Sensor
Four-wire Sensor
Data Cable up to
15 ft. / 3m in
length
Sensor Data
Cable
