GASMAX/TX Operation & Maintenance Manual, Revision 1.0
Page 49
14 DRAWINGS AND DIMENSIONS
Figure 14-1: GASMAX/TX Dimensions (Single Local Sensor)
5.1”
5.00”
15.1” with 900 MHz antenna
19.2” with 2.4 GHz antenna
