GE AF-600 FP Series Design And Installation Guide

Illustration 1.5 Position of Earth Terminals IP21 (NEMA Type 1)
and IP54 (NEMA Type 12)
Illustration 1.6 Rectifier Cabinet, unit sizes 61, 62, 63 and 64
1) 24 V DC, 5 A 5) Loadsharing
T1 Output Taps -DC +DC
Temp Switch 88 89
106 104 105 6) Control Transformer Fuses (2 or 4 pieces). See 13.3 Fuse Specifications for part
numbers
2) Manual Motor Starters 7) SMPS Fuse. See 13.3 Fuse Specifications for part numbers
3) 30 A Fuse Protected Power Terminals 8) Manual Motor Controller fuses (3 or 6 pieces). See 13.3 Fuse Specifications for part
numbers
4) Line 9) Line Fuses, unit sizes 61 and 62 (3 pieces). See 13.3 Fuse Specifications for part
numbers
R S T 10) 30 Amp Fuse Protected Power fuses
L1 L2 L3
Table 1.5 Legend to Illustration 1.6
Introduction
AF-600 FP
TM
Design and Installation Guide
DET-768b 9
1
1
