GE AF-650 GP

Recommended max. fuse
AF-650
GP
Bussmann PN
Alternate
External
Bussmann PN
Alternate
External
Bussmann PN
Alternate
External
Siba PN
Alternate External
Littlefuse PN
Alternate
External
Ferraz-
Shawmut PN
Alternate External
Ferraz-Shawmut PN
[kW]/
[HP]
Type JFHR2 Type JFHR2 Type T/JDDZ Type JFHR2 Type JFHR2 Type JFHR2
90/125 170M3017 FWH-300 JJS-300 2028220-315 L50-S-300 A50-P-300
110/
150
170M3018 FWH-350 JJS-350 2028220-315 L50-S-350 A50-P-350
132/
200
170M4012 FWH-400 JJS-400 206xx32-400 L50-S-400 A50-P-400
160/
250
170M4014 FWH-500 JJS-500 206xx32-500 L50-S-500 A50-P-500
200/
300
170M4016 FWH-600 JJS-600 206xx32-600 L50-S-600 A50-P-600
250/
350
170M4017 20 610 32.700 6.9URD31D08A0700
315/
450
170M6013 22 610 32.900 6.9URD33D08A0900
355/
500
170M6013 22 610 32.900 6.9URD33D08A0900
400/
550
170M6013 22 610 32.900 6.9URD33D08A0900
450/
600
170M7081
500/
650
170M7081
560/
750
170M7082
630/
900
170M7082
710/
1,000
170M7083
800/
1200
170M7083
Table 13.21 380–480 V, above 125 HP
AF-650 GP Bussmann PN Rating Alternate Siba PN
[kW]/[HP]
450/600 170M8611 1,100 A, 1,000 V 20 781 32.1000
500/650 170M8611 1,100 A, 1,000 V 20 781 32.1000
560/750 170M6467 1,400 A, 700 V 20 681 32.1400
630/900 170M6467 1,400 A, 700 V 20 681 32.1400
710/1,000 170M8611 1,100 A, 1,000 V 20 781 32.1000
800/1200 170M6467 1,400 A, 700 V 20 681 32.1400
Table 13.22 380–480 V, 600 HP and above
