GE AF-650 GP

AF-650 GP Bussmann PN
Alternate External
Siba PN
Alternate External
Ferraz-Shawmut PN
[kW]/[HP] Type JFHR2 Type JFHR2
90/125 170M3017 2061032,315 6.9URD30D08A0315
110/150 170M3018 2061032,35 6.9URD30D08A0350
132/200 170M4011 2061032,35 6.9URD30D08A0350
160/250 170M4012 2061032,4 6.9URD30D08A0400
200/300 170M4014 2061032,5 6.9URD30D08A0500
250/350 170M5011 2062032,55 6.9URD32D08A0550
315/400 170M4017 20 610 32.700 6.9URD31D08A0700
335/450 170M4017 20 610 32.700 6.9URD31D08A0700
355/500 170M6013 22 610 32.900 6.9URD33D08A0900
415/600 170M6013 22 610 32.900 6.9URD33D08A0900
500/650 170M7081
560/750 170M7081
710/950 170M7081
785/1050 170M7081
800/1150 170M7082
1,000/1,350 170M7083
Table 13.23 525–690 V, above 125 HP
AF-650 GP Bussmann PN Rating Alternate Siba PN
[kW]/[HP]
630/900 170M8611 1,100 A, 1,000 V 20 781 32.1000
710/1,000 170M8611 1,100 A, 1,000 V 20 781 32.1000
800/1150 170M8611 1,100 A, 1,000 V 20 781 32.1000
900/1250 170M8611 1,100 A, 1,000 V 20 781 32.1000
1,000/1,350 170M8611 1,100 A, 1,000 V 20 781 32.1000
1200/1600 170M8611 1,100 A, 1,000 V 20 781 32.1000
Table 13.24 525–690 V, 900 HP and above
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use
**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL requirements.
