5.5.2 Main Menu
Structure
Keypad setup
K-0# Keypad Basic Settings
K-01 Language
K-02 Motor Speed Unit
K-03 Regional Settings
K-04 Operating State at Power-up
K-09 Performance Monitor
K-1# Keypad Setup Operations
K-10 Active Setup
K-11 Edit Setup
K-12 This Setup Linked to
K-13 Readout: Linked Setups
K-14 Readout: Edit Setups / Channel
K-2# Keypad Display
K-20 Display Line 1.1 Small
K-21 Display Line 1.2 Small
K-22 Display Line 1.3 Small
K-23 Display Line 2 Large
K-24 Display Line 3 Large
K-25 Quick Start
K-3# Keypad Custom Readout
K-30 Unit for Custom Readout
K-31 Min Value of Custom Readout
K-32 Max Value of Custom Readout
K-37 Display Text 1
K-38 Display Text 2
K-39 Display Text 3
K-4# Keypad Buttons
K-40 [Hand] Button on Keypad
K-41 [Off] Button on Keypad
K-42 [Auto] Button on Keypad
K-43 [Reset] Button on Keypad
K-44 [Off/Reset] Key on Keypad
K-5# Copy/Save
K-50 Keypad Copy
K-51 Setup Copy
K-6# Password Protection
K-60 Main Menu Password
K-61 Access to Main Menu w/o Password
K-65 Quick Menu Password
K-66 Access to Quick Menu w/o Password
K-67 Bus Password Access
Parameter Data Set
F-## Fundamental Parameters
F-0# Fundamental 0
F-05 Motor Rated Voltage
F-04 Base Frequency
F-09 Torque Boost
F-02 Operation Method
F-01 Frequency Setting 1
F-07 Accel Time 1
F-08 Decel Time 1
F-03 Max Output Frequency 1
F-1# Fundamental 1
F-10 Electronic Overload
F-11 Motor External Fan
F-12 Motor Thermistor Input
F-18 Motor Speed Low Limit [RPM]
F-16 Motor Speed Low Limit [Hz]
F-17 Motor Speed High Limit [RPM]
F-15 Motor Speed High Limit [Hz]
F-2# Fundamental 2
F-24 Holding Time
F-25 Start Function
F-22 Start Speed [RPM]
F-23 Start Speed [Hz]
F-29 Start Current
F-26 Motor Noise (Carrier Freq)
F-27 Motor Tone Random
F-28 Dead Time Compensation
F-3# Fundamental 3
F-37 Adv. Switching Pattern
F-38 Overmodulation
F-4# Fundamental 4
F-40 Torque Limiter (Driving)
F-41 Torque Limiter (Braking)
F-43 Current Limit
F-5# Extended References
F-50 Reference Range
F-51 Reference/Feedback Unit
F-52 Minimum Reference
F-53 Maximum Reference
F-54 Reference Function
F-6# References
F-62 Catch up/slow-down value
F-64 Preset Relative Reference
F-68 Relative Scaling Reference Resource
F-9# Digital Potentiometer
F-90 Step Size
F-91 Accel/Decel Time
F-92 Power Restore
F-93 Maximum Limit
F-94 Minimum Limit
F-95 Accel/Decel Ramp Delay
E-## Digital In/Out
E-0# Digital Inputs
E-00 Digital I/O Mode
E-01 Terminal 18 Digital Input
E-02 Terminal 19 Digital Input
E-03 Terminal 27 Digital Input
E-04 Terminal 29 Digital Input
E-05 Terminal 32 Digital Input
E-06 Terminal 33 Digital Input
E-07 Terminal 37 Safe Stop
E-1# Additional Accel Decel Ramps
E-10 Accel Time 2
E-11 Decel Time 2
E-12 Accel Time 3
E-13 Decel Time 3
E-14 Accel Time 4
E-15 Decel Time 4
E-2# Digital Output
E-20 Terminal 27 Digital Output
E-21 Terminal 29 Digital Output
E-24 Function Relay
E-26 On Delay, Relay
E-27 Off Delay, Relay
E-3# X46 Digital Inputs
E-30 Terminal X46/1 Digital Input
E-31 Terminal X46/3 Digital Input
E-32 Terminal X46/5 Digital Input
E-33 Terminal X46/7 Digital Input
E-34 Terminal X46/9 Digital Input
E-35 Terminal X46/11 Digital Input
E-36 Terminal X46/13 Digital Input
E-5# I/O Mode / Add On I/O
E-51 Terminal 27 Mode
E-52 Terminal 29 Mode
E-53 Terminal X30/2 Digital Input
E-54 Terminal X30/3 Digital Input
E-55 Terminal X30/4 Digital Input
E-56 Term X30/6 Digi Out (OPCGPIO)
E-57 Term X30/7 Digi Out (OPCGPIO)
E-6# Pulse Input
E-60 Term. 29 Low Frequency
E-61 Term. 29 High Frequency
E-62 Term. 29 Low Ref./Feedb. Value
E-63 Term. 29 High Ref./Feedb. Value
E-64 Pulse Filter Time Constant #29
E-65 Term. 33 Low Frequency
E-66 Term. 33 High Frequency
E-67 Term. 33 Low Ref./Feedb. Value
E-68 Term. 33 High Ref./Feedb. Value
E-69 Pulse Filter Time Constant #33
E-7# Pulse Output
E-70 Terminal 27 Pulse Output Variable
E-72 Pulse Output Max Freq #27
E-73 Terminal 29 Pulse Output Variable
E-75 Pulse Output Max Freq #29
E-76 Terminal X30/6 Pulse Output Variable
E-78 Pulse Output Max Freq #X30/6
E-8# 24 V Encoder Input
E-80 Term 32/33 Pulses Per Revolution
E-81 Term 32/33 Encoder Direction
E-9# Bus Controlled
E-90 Digital & Relay Bus Control
E-93 Pulse Out #27 Bus Control
E-94 Pulse Out #27 Timeout Preset
E-95 Pulse Out #29 Bus Control
E-96 Pulse Out #29 Timeout Preset
E-97 Pulse Out #X30/6 Bus Control
E-98 Pulse Out #X30/6 Timeout Preset
C-## Frequency Control Functions
C-0# Frequency Control Functions
C-05 Multi-step Frequency 1 - 8
C-02 Jump Speed From [RPM]
C-01 Jump Frequency From [Hz]
C-03 Jump Speed To [RPM]
C-04 Jump Frequency To [Hz]
C-2# Jog Setup
C-20 Jog Speed [Hz]
C-21 Jog Speed [RPM]
C-22 Jog Accel/Decel Time
C-23 Quick Stop Decel Time
C-24 Quick Stop Ramp Type
C-25 Quick Stop S-ramp Ratio at Decel.
Start
C-26 Quick Stop S-ramp Ratio at Decel.
End
C-3# Frequ. Set. 2 and 3
C-30 Frequency Command 2
C-34 Frequency Command 3
P-## Motor Data
P-0# Motor Data
P-07 Motor Power [kW]
P-02 Motor Power [HP]
P-03 Motor Current
P-06 Base Speed
P-05 Motor Cont. Rated Torque
P-04 Auto Tune
P-01 Motor Poles
P-09 Slip Compensation
P-10 Slip Compensation Time Constant
P-2# Motor Selection
P-20 Motor Construction
P-3# Adv. Motor Data
P-30 Stator Resistance (Rs)
P-31 Rotor Resistance (Rr)
P-33 Stator Leakage Reactance (X1)
P-34 Rotor Leakage Reactance (X2)
P-35 Main Reactance (Xh)
P-36 Iron Loss Resistance (Rfe)
P-37 d-axis Inductance (Ld)
H-## High Perf Parameters
H-0# High Perf Operations
H-09 Start Mode
H-07 Accel/Decel Time 1 Type
H-08 Reverse Lock
H-04 Auto-Reset (Times)
H-05 Auto-Reset (Reset Interval)
H-03 Restore Factory Settings
H-2# Motor Feedback Monitoring
H-20 Motor Feedback Loss Function
H-21 Motor Feedback Speed Error
H-22 Motor Feedback Loss Timeout
H-24 Tracking Error Function
H-25 Tracking Error
H-26 Tracking Error Timeout
H-27 Tracking Error Ramping
H-28 Tracking Error Ramping Timeout
H-29 Tracking Error After Ramping
Timeout
H-4# Advanced Settings
H-40 Configuration Mode
H-41 Motor Control Principle
H-42 Flux Motor Feedback Source
H-43 Torque Characteristics
H-44 Constant or Variable Torque OL
H-45 Local Mode Configuration
H-48 Clockwise Direction
H-46 Back EMF at 1,000 RPM
H-47 Motor Angle Offset
H-5# Load Indep. Settings
H-50 Motor Magnetization at Zero Speed
H-51 Min Speed Normal Magnetizing
[RPM]
H-52 Min Speed Normal Magnetizing [Hz]
H-53 Model Shift Frequency
H-54 Voltage reduction in field weakening
H-55 U/f Characteristic - U
H-56 U/f Characteristic - F
H-58 Flystart Test Pulses Current
H-59 Flystart Test Pulses Frequency
H-6# Load Depen. Settings
H-61 High Speed Load Compensation
H-64 Resonance Dampening
H-65 Resonance Dampening Time
Constant
H-66 Min. Current at Low Speed
H-7# Adj. Warnings
H-70 Warning Current Low
H-71 Warning Current High
H-72 Warning Speed Low
H-73 Warning Speed High
H-74 Warning Reference Low
H-75 Warning Reference High
H-76 Warning Feedback Low
H-77 Warning Feedback High
H-78 Missing Motor Phase Function
H-8# Stop Adjustments
H-87 Load Type
H-88 Minimum Inertia
H-89 Maximum Inertia
H-80 Function at Stop
H-81 Min Speed for Function at Stop
[RPM]
H-82 Min Speed for Function at Stop [Hz]
H-83 Precise Stop Function
H-84 Precise Stop Counter Value
H-85 Precise Stop Speed Compensation
Delay
H-9# Motor Temperature
H-95 KTY Sensor Type
H-96 KTY Thermistor Input
H-97 KTY Threshold level
AN-## Analog In / Out
AN-0# Analog I/O Mode
AN-00 Live Zero Timeout Time
AN-01 Live Zero Timeout Function
AN-1# Analog Input 53
AN-10 Terminal 53 Low Voltage
AN-11 Terminal 53 High Voltage
AN-12 Terminal 53 Low Current
AN-13 Terminal 53 High Current
AN-14 Terminal 53 Low Ref./Feedb. Value
AN-15 Terminal 53 High Ref./Feedb. Value
AN-16 Terminal 53 Filter Time Constant
AN-2# Analog Input 54
AN-20 Terminal 54 Low Voltage
AN-21 Terminal 54 High Voltage
AN-22 Terminal 54 Low Current
About Programming
AF-650 GP
TM
Design and Installation Guide
5-6 DET-767A
5
