AN-23 Terminal 54 High Current
AN-24 Terminal 54 Low Ref./Feedb. Value
AN-25 Terminal 54 High Ref./Feedb. Value
AN-26 Terminal 54 Filter Time Constant
AN-3# Analog Input X30/11
AN-30 Terminal X30/11 Low Voltage
AN-31 Terminal X30/11 High Voltage
AN-34 Term. X30/11 Low Ref./Feedb. Value
AN-35 Term. X30/11 High Ref./Feedb. Value
AN-36 Term. X30/11 Filter Time Constant
AN-4# Analog Input X30/12
AN-40 Terminal X30/12 Low Voltage
AN-41 Terminal X30/12 High Voltage
AN-44 Term. X30/12 Low Ref./Feedb. Value
AN-45 Term. X30/12 High Ref./Feedb. Value
AN-46 Term. X30/12 Filter Time Constant
AN-5# Analog Output 42
AN-50 Terminal 42 Output
AN-51 Terminal 42 Output Min Scale
AN-52 Terminal 42 Output Max Scale
AN-53 Terminal 42 Output Bus Control
AN-54 Terminal 42 Output Timeout Preset
AN-55 Terminal 42 Output Filter
AN-6# Analog Output X30/8
AN-60 Terminal X30/8 Output
AN-61 Terminal X30/8 Min. Scale
AN-62 Terminal X30/8 Max. Scale
AN-63 Terminal X30/8 Bus Control
AN-64 Terminal X30/8 Output Timeout
Preset
AN-7# Analog Output X45/1
AN-70 Terminal X45/1 Output
AN-71 Terminal X45/1 Min. Scale
AN-72 Terminal X45/1 Max. Scale
AN-73 Terminal X45/1 Bus Control
AN-74 Terminal X45/1 Output Timeout
Preset
AN-8# Analog Output X45/3
AN-80 Terminal X45/3 Output
AN-81 Terminal X45/3 Min. Scale
AN-82 Terminal X45/3 Max. Scale
AN-83 Terminal X45/3 Bus Control
AN-84 Terminal X45/3 Output Timeout
Preset
SP-## Special Functions
SP-0# Fault Settings
SP-00 Fault Level
SP-1# Line On/Off
SP-10 Line failure
SP-11 Line Voltage at Input Fault
SP-12 Function at Line Imbalance
SP-13 Line Failure Step Factor
SP-2# Reset Functions
SP-23 Typecode Setting
SP-24 Trip Delay at Current Limit
SP-25 Trip Delay at Torque Limit
SP-26 Trip Delay at Drive Fault
SP-28 Production Settings
SP-29 Service Code
SP-3# Current Limit Ctrl.
SP-30 Current Limit Cntrl, Proportional Gain
SP-31 Current Limit Cntrl, Integration Time
SP-32 Current Lim Ctrl, Filter Time
SP-35 Stall Protection
SP-4# Energy Savings
SP-40 VT Level
SP-41 Energy Savings Min. Magnetization
SP-42 Energy Savings Min. Frequency
SP-43 Motor Cos Phi
SP-5# Environment
SP-50 RFI Filter
SP-51 DC Link Compensation
SP-52 Fan Operation
SP-53 Fan Monitor
SP-55 Output Filter
SP-56 Capacitance Output Filter
SP-57 Inductance Output Filter
SP-59 Actual Number of Inverter Units
SP-6# Automatic Derate
SP-63 Option Supplied by External 24VDC
SP-7# Add ACC/DEC settings
SP-71 Accel Time 1 S-ramp Ratio at Accel.
Start
SP-72 Accel Time 1 S-ramp Ratio at Accel.
End
SP-73 Decel Time 1 S-ramp Ratio at Decel.
Start
SP-74 Decel Time 1 S-ramp Ratio at Decel.
End
SP-76 Accel/Decel Time 2 Type
SP-79 Accel Time 2 S-ramp Ratio at Accel.
Start
SP-80 Accel Time 2 S-ramp Ratio at Accel.
End
SP-81 Decel Time 2 S-ramp Ratio at Decel.
Start
SP-82 Decel Time 2 S-ramp Ratio at Decel.
End
SP-84 Accel/Decel Ramp 3 Type
SP-87 Accel Time 3 S-ramp Ratio at Accel.
Start
SP-88 Accel Time 3 S-ramp Ratio at Accel.
End
SP-89 Decel Time 3 S-ramp Ratio at Decel.
Start
SP-90 Decel Time 3 S-ramp Ratio at Decel.
End
SP-92 Accel/Decel Ramp 4 Type
SP-95 Accel Time 4 S-ramp Ratio at Accel.
Start
SP-96 Accel Time 4 S-ramp Ratio at Accel.
End
SP-97 Decel Time 4 S-ramp Ratio at Decel.
Start
SP-98 Decel Time 4 S-ramp Ratio at Decel.
End
O-## Options / Comms
O-0# General Settings
O-01 Control Site
O-02 Control Word Source
O-03 Control Word Timeout Time
O-04 Control Word Timeout Function
O-05 End-of-Timeout Function
O-06 Reset Control Word Timeout
O-07 Diagnosis Trigger
O-08 Readout Filtering
O-1# Control Settings
O-10 Control Word Profile
O-13 Configurable Status Word STW
O-14 Configurable Control Word CTW
O-3# Drive Port Settings
O-30 Protocol
O-31 Address
O-32 Drive Port Baud Rate
O-33 Drive port parity
O-34 Estimated cycle time
O-35 Minimum Response Delay
O-36 Max Response Delay
O-37 Max Inter-Char Delay
O-4# Drive MC Port Set.
O-40 Telegram Selection
O-41 Parameters for Signals
O-42 PCD Write Configuration
O-43 PCD Read Configuration
O-5# Digital / Bus
O-50 Coasting Select
O-51 Quick Stop Select
O-52 DC Brake Select
O-53 Start Select
O-54 Reversing Select
O-55 Setup Select
O-56 Preset Reference Select
O-57 Profidrive OFF2 Select
O-58 Profidrive OFF3 Select
O-8# Drive Port Diagnostics
O-80 Bus Message Count
O-81 Bus Error Count
O-82 Slave Messages Rcvd
O-83 Slave Error Count
O-9# Bus Jog / Feedback
O-90 Bus Jog 1 Speed
O-91 Bus Jog 2 Speed
DN-## Devicenet serial communication bus
DN-0# Common Settings
DN-00 DeviceNet Protocol
DN-01 Baud Rate Select
DN-02 MAC ID
DN-05 Readout Transmit Error Counter
DN-06 Readout Receive Error Counter
DN-07 Readout Bus Off Counter
DN-1# DeviceNet
DN-10 Process Data Type Selection
DN-11 Process Data Config Write
DN-12 Process Data Config Read
DN-13 Warning Parameter
DN-14 Net Reference
DN-15 Net Control
DN-18 internal_process_data_config_write
DN-19 internal_process_data_config_read
DN-2# COS Filters
DN-20 COS Filter 1
DN-21 COS Filter 2
DN-22 COS Filter 3
DN-23 COS Filter 4
DN-3# Parameter Access
DN-30 Array Index
DN-31 Store Data Values
DN-32 Devicenet Revision
DN-33 Store Always
DN-34 DeviceNet Product Code
DN-39 Devicenet F Parameters
DN-5# DeviceNet Proc Data
PB-## Profibus
K-11 Edit Setup
PB-00 Setpoint
PB-07 Actual Value
PB-15 PCD Write Configuration
PB-16 PCD Read Configuration
PB-18 Node Address
PB-22 Telegram Selection
PB-23 Parameters for Signals
PB-27 Parameter Edit
PB-28 Process Control
PB-44 Fault Message Counter
PB-45 Fault Code
PB-47 Fault Number
PB-52 Fault Situation Counter
PB-53 Profibus Warning Word
PB-63 Actual Baud Rate
PB-64 Device Identification
PB-65 Profile Number
PB-67 Control Word 1
PB-68 Status Word 1
PB-71 Profibus Save Data Values
PB-72 ProfibusDriveReset
PB-80 Defined Parameters (1)
PB-81 Defined Parameters (2)
PB-82 Defined Parameters (3)
PB-83 Defined Parameters (4)
PB-84 Defined Parameters (5)
PB-90 Changed Parameters (1)
PB-91 Changed Parameters (2)
PB-92 Changed Parameters (3)
PB-93 Changed parameters (4)
PB-94 Changed parameters (5)
PB-99 Profibus Revision Counter
EN-## Ethernet IP
EN-0# IP Settings
EN-00 IP Address Assignment
EN-01 IP Address
EN-02 Subnet Mask
EN-03 Default Gateway
EN-04 DHCP Server
EN-05 Lease Expires
EN-06 Name Servers
EN-07 Domain Name
EN-08 Host Name
EN-09 Physical Address
EN-1# Ethernet Link Parameters
EN-10 Link Status
EN-11 Link Duration
EN-12 Auto Negotiation
EN-13 Link Speed
EN-14 Link Duplex
EN-2# Process Data
EN-20 Control Instance
EN-21 Process Data Config Write
EN-22 Process Data Config Read
EN-28 Store Data Values
EN-29 Store Always
EN-3# EtherNet/IP
EN-30 Warning Parameter
EN-31 Net Reference
EN-32 Net Control
EN-33 CIP Revision
EN-34 CIP Product Code
EN-35 EDS Parameter
EN-37 COS Inhibit Timer
EN-38 COS Filter
EN-4# Modbus TCP
EN-40 Status Parameter
EN-41 Slave Message Count
EN-42 Slave Exception Message Count
EN-8# Other Ethernet Services
EN-80 FTP Server
EN-81 HTTP Server
EN-82 SMTP Service
EN-89 Transparent Socket Channel Port
EN-9# Advanced Ethernet Services
EN-90 Cable Diagnostic
EN-91 MDI-X
EN-92 IGMP Snooping
EN-93 Cable Error Length
EN-94 Broadcast Storm Protection
EN-95 Broadcast Storm Filter
EN-96 Port Mirroring
EN-98 Interface Counters
EN-99 Media Counters
EC-## Feedback Option
EC-1# Inc. Enc. Interface
EC-10 Signal Type
EC-11 Resolution (PPR)
EC-2# Abs. Enc. Interface
EC-20 Protocol Selection
EC-21 Resolution (Positions/Rev)
EC-24 SSI Data Length
EC-25 Clock Rate
EC-26 SSI Data Format
EC-34 HIPERFACE Baud rate
EC-6# Monitoring and App.
EC-60 Feedback Direction
EC-61 Feedback Signal Monitoring
RS-## Resolver Interface
RS-50 Poles
RS-51 Input Voltage
About Programming
AF-650 GP
TM
Design and Installation Guide
