49-5000427 Rev. 0 7
Using the Dehumidifier
Removing Collected Water (Continued)
Water Level
The dehumidifier will turn off automatically when the bucket
is full, or when the bucket is removed or not replaced in the
proper position.
The bucket must be replaced in the proper position for the
dehumidifier to work. The bucket full light will be on and the
dehumidifier will not run if the bucket is not in the proper
position.
Bucket Operation
DO NOT remove the foam piece in the bucket assembly.
If removed the Dehumidifier will not work properly.
When the coil is defrosted, the compressor or fan will
automatically restart and dehumidifying will resume.
OPERATING INSTRUCTIONS
To Install Hose: Push in hose and gently pull to make
sure it is secure. Should not be able to be removed.
To Release Hose: Hold the grey ring while pulling to
remove.
NOTE: DO NOT kink or crimp hose, as it can block water
flow.
Push hose in
1. Hold grey ring in
2. Pull hose out
To Next Page
