GE ASTAT Plus - Advanced Functions and Parameters

4. Programming
4-7
Programmable Basic Functions (follow from previous page)
By-pass selector
DC Brake selector
z xxx
B xxx
z OF F
B OF F
This function provides control of an external by-pass contactor,
significantly lowering heating losses and eliminating harmonics.
When the By-Pass function z is enabled, the programmable relay
output 2r is automatically assigned to this function, and must be used
to control the external by-pass contactor
Enables or disables the DC brake function
When the DC Brake function B is enabled, the programmable relay
output 3r is automatically assigned to this function.
PON, PI3 or PI4 settings enable the DC Brake function just before
starting the motor. This is usefull to stop a fan which is rotating in
reverse at the starting time
OFF, ON, I3, I4
OFF, ON, I3, I4,
PON, PI3, PI4
Function
Display Description
Default Range Unit
4-6. Advanced Block Parameters -ADV-
Lock-Out
E2PROM reading
Factory settings
Retry
Retry time
Undervoltage
Undervoltage trip time
Overvoltage
Overvoltage trip time
Undercurrent
Undercurrent trip time
Overcurrent
Overcurrent trip time
Dual Ramp Up
Dual Ramp Down
Dual StartingTorque
LKxx
R xxx
Q xxx
Y x
y xx
UVxx
uvxx
OVxx
ovxx
UCxx
ucxx
OCxx
ocxx
2axx
2dxx
2Txx
LK00
R OF F
Q OF F
Y 0
y 10
UV00
uv20
OV00
ov20
UC00
uc20
OC00
oc20
2a20
2d20
2T20
Sets time between consecutive starts. Setting "0" disables
this function.
Loads the parameters from the E2PROM to the temporal
buffer
Loads default factory settings to the temporal buffer.
Allows up to four tries of automatic restart after a fault.
Setting 0 disables this function.
Time between retries.
The unit trips if the line voltage decreases below the
percentage set. Setting 0 disables this protection.
Note: Calibrate parameter U before enabling this
protection.
Delay trip time
The unit trips if the line voltage increases above the per-
centage set. Setting 0 disables this protection.
Note: Calibrate parameter U before enabling this
protection.
Delay trip time
The unit trips if the current decreases below the percent-
age set. Setting 0 disables this protection.
Note: Calibrate parameter U before enabling this
protection.
Delay trip time
The unit trips if the current increases above the percent-
age set. Setting 0 disables this protection.
Note: Calibrate parameter U before enabling this
protection.
Delay trip time.
These are a secondary set of ramp up, ramp down and
starting torque parameters, which take over the primary
"a", "d" and "T" when the programmable function A is
enabled.
00-45
ON, OFF
ON, OFF
0-4
01-99
00-50
00-99
00-30
00-99
00-99
00-99
00-50
00-99
01-99
01-99
10-90
min.
-
-
-
sec.
%
sec.
%
sec.
%
sec.
%
sec.
sec.
sec.
%
4-6-1. Advanced Functions
