GE ASTAT Plus - Supply Wiring and Protection; Fuses, Contactors, and Supply Wiring

5-2. Fuses, contactors and supply wiring
In Total Fuses Fuses Fuses Control voltage Contactor Contactor Conductor
losses aM FERRAZ type BUSSMANN type DC 1 DC 3 section
100% In (F1) (XX=according (Typower Sicu 660V~) Fuse Consumpt. (2)
Cat Number A W A mech. design) Size In A VA mm
2
QC _ F DP 17 67 25 6,600 CP URC 14.51/40 00 40 1 18 CL02 CL02 4
QC _ G DP 21 78 32 6,6 URD 30 XX 0063 00 50 1 18 CL03 CL03 4
QC _ H DP 27 88 40 6,6 URD 30 XX 0080 00 80 1 18 CL04 CL03 6
QC _ I DP 38 116 63 6,6 URD 30 XX 0100 00 100 1 18 CL45 CL04 10
QC _ J DP 58 208 80 6,6 URD 30 XX 0125 00 125 2 55 CL07 CL45 16
QC _ K DP 75 277 100 6,6 URD 30 XX 0160 00 160 2 55 CL08 CL06 25
QC _ L DP 86 302 125 6,6 URD 30 XX 0160 00 200 2 55 CL09 CL06 35
QC _ M DP 126 389 200 6,6 URD 30 XX 0250 00 250 2 55 CK75 CL07 50
QC _ N DP 187 719 250 6,6 URD 30 XX 0315 00 315 2 78 CK08 CL10 95
QC _ Q DP 288 1097 400 6,6 URD 31 XX 0500 2 550 2 78 CK95 CK85 185
QC _ R DP 378 1286 500 6,6 URD 31 XX 0630 2 630 4 118 CK10 CK85 240
QC _ S DP 444 1374 630 6,6 URD 32 XX 0800 2 800 4 118 CK11 CK95 Bus bar (1)
QC _ T DP 570 2086 800 6,6 URD 33 XX 1000 3 1000 4 118 CK12 CK10 Bus bar (1)
QC _ U DP 732 2352 1000 6,6 URD 33 XX 1250 3 1250 4 248 CK12 CK10 Bus bar (1)
QC _ V DP 1020 3000 1250 6,6 URD 233 XX 2000 - - 4 248 CK13 CK11 Bus bar (1)
QC _ X DP 1290 3839 2x800 6,6 URD 233 XX 2000 - - 4 248 CK13 CK12 Bus bar (1)
5. Installation
In Total Fuses Fuses Fuses Control voltage Contactor Contactor Conductor
losses aM FERRAZ type BUSSMANN type DC 1 DC 3 section
100% In (F1) (XX=according (Typower Sicu 660V~) Fuse Consumpt. (2)
Cat Number A W A mech. design) Size In A VA mm
2
QC _ F DP 14 56 20 6,600 CP URC 14.51/40 00 40 1 18 CL01 CL01 4
QC _ G DP 17 65 25 6,6 URD 30 XX 0063 00 50 1 18 CL02 CL02 4
QC _ H DP 22 74 32 6,6 URD 30 XX 0080 00 80 1 18 CL03 CL03 4
QC _ I DP 32 99 63 6,6 URD 30 XX 0100 00 100 1 18 CL04 CL04 6
QC _ J DP 48 178 80 6,6 URD 30 XX 0125 00 125 2 55 CL06 CL04 10
QC _ K DP 63 236 80 6,6 URD 30 XX 0160 00 160 2 55 CL07 CL04 16
QC _ L DP 72 257 100 6,6 URD 30 XX 0160 00 200 2 55 CL08 CL06 25
QC _ M DP 105 325 160 6,6 URD 30 XX 0250 00 250 2 55 CL10 CL06 35
QC _ N DP 156 591 200 6,6 URD 30 XX 0315 00 315 2 78 CK75 CL07 70
QC _ Q DP 240 901 315 6,6 URD 31 XX 0500 2 550 2 78 CK85 CK75 120
QC _ R DP 315 1063 400 6,6 URD 31 XX 0630 2 630 4 118 CK95 CK85 185
QC _ S DP 370 1136 500 6,6 URD 32 XX 0800 2 800 4 118 CK10 CK85 240
QC _ T DP 475 1721 630 6,6 URD 33 XX 1000 3 1000 4 118 CK11 CK95 Bus bar (1)
QC _ U DP 610 1950 800 6,6 URD 33 XX 1250 3 1250 4 248 CK12 CK10 Bus bar (1)
QC _ V DP 850 2491 1000 6,6 URD 233 XX 2000 - - 4 248 CK13 CK10 Bus bar (1)
QC _ X DP 1075 3168 1250 6,6 URD 233 XX 2000 - - 4 248 CK13 CK12 Bus bar (1)
(1) As per IEC 947 (2) The 3 contacts of DC3 must be connected in parallel
IEC Class 10
Ratings
5-2
IEC Class 20
Ratings
Max. Fuse Max. Circuit
Type Type Rating Class Breaker Non-
Cat Number A50QS
1
A50P
2
RK5 & J Size Combination Combination <Remarks>
QC _ F DP 50A - 30A 35A 25KA 5KA
QC _ G DP 60A - 35A 40A 25KA 5KA
QC _ H DP 80A - 40A 50A 25KA 5KA
QC _ I DP 100A - 70A 80A 25KA 5KA
QC _ J DP 150A - 100A 125A 25KA 10KA
QC _ K DP 200A - 125A 150A 25KA 10KA
QC _ L DP 225A - 150A 150A 25KA 10KA
QC _ M DP 350A - 200A 250A 25KA 10KA
QC _ N DP 450A - 350A 350A 65KA 25KA
QC _ Q DP 600A - 500A 600A 65KA 25KA
QC _ R DP 2X500A in parallel - 600A 700A 65KA 25KA
QC _ S DP 2x600A in parallel - 600A 800A 65KA 25KA
QC _ T DP - 2x1000A in parallel - 800A 65KA 30KA
*2
QC _ U DP - 2x1200A in parallel - 1000A 65KA 30KA
*2
QC _ V DP - 2x1600A in parallel - 1200A 65KA 65KA
Branch Circuit Protection, UL
Gould-Shawmut, semi-conductor fuses Short-Circuit Rating Max @480V
Note: When ASTAT Plus reduced voltage starters are used in conjunction with semi-conductor fuses, Typen 2 Co-ordination to IEC 947-4 is attained. These
fuses are recommended for best overall short-circuit protection. The semiconductor fuse specified may provide branch circuit protection. Refer to local
applicable electrical codes
(
1
) Suitable for use on a circuit capable of
delivering not more than 100KA RMS
symetrical amperes, for 208V, 240V and up to
480V maximum, when used with the semi-
conductor fuse for short-circuit protection. Listed
with Gould Shawmut Form 101, Type A5QS or
A50P
(
2
) Suitable for use on a circuit capable of
delivering not more than 65KA RMS symetrical
amperes, for 208V, 240V and up to 480V
maximum, when used with contactors (isolation
or by-pass) that are also rated for 65KA
withstand.
