GE ASTAT Plus - IEC Ratings; Section 2. Types and Ratings

HEAVY DUTY LIGHT DUTY Degree of TYPE Weight Cooled
Current 220V / 380V / 440V 480V / Current 220V / 380V / 440V 480V / protection unit
rating (2) 240V 415V 500V rating (3) 240V 415V 500V
A kW(4) kW(4) kW(4) kW(4) A kW(5) kW(5) kW(5) kW(5) Kg. Lbs.
14 3 5.5 7.5 - 17 4 7.5 7.5 - IP-00 QC1FDP 4.3 9.48 Natural
3 5.5 7.5 7.5 4 7.5 7.5 11 IP-00 QC2FDP 4.3 9.48 Natural
17 4 7.5 7.5 - 21 5.5 11 11 - IP-00 QC1GDP 4.3 9.48 Natural
4 7.5 7.5 11 5.5 11 11 13 IP-00 QC2GDP 4.3 9.48 Natural
22 5.5 11 11 - 27 7.5 13 15 - IP-00 QC1HDP 4.6 10.14 Natural
5.5 11 11 15 7.5 13 15 15 IP-00 QC2HDP 4.6 10.14 Natural
32 7.5 15 18.5 - 38 10 18.5 22 - IP-00 QC1IDP 4.6 10.14 Natural
7.5 15 18.5 22 10 18.5 22 25 IP-00 QC2IDP 4.6 10.14 Natural
48 13 22 22 - 58 15 25 30 - IP-00 QC1JDP 12.5 27.56 By fan
13 22 22 30 15 25 30 37 IP-00 QC2JDP 12.5 27.56 By fan
63 15 30 37 - 75 22 37 45 - IP-00 QC1KDP 12.5 27.56 By fan
15 30 37 37 22 37 45 45 IP-00 QC2KDP 12.5 27.56 By fan
72 20 37 37 - 86 25 45 50 - IP-00 QC1LDP 17.0 37.48 By fan
20 37 37 45 25 45 50 50 IP-00 QC2LDP 17.0 37.48 By fan
105 30 55 55 - 126 37 63 75 - IP-00 QC1MDP 17.0 37.48 By fan
30 55 55 75 37 63 75 80 IP-00 QC2MDP 17.0 37.48 By fan
156 40 75 90 - 187 55 90 110 - IP-00 QC1NDP 45.0 99.20 By fan
40 75 90 110 55 90 110 132 IP-00 QC2NDP 45.0 99.20 By fan
240 63 110 132 - 288 80 150 165 - IP-00 QC1QDP 45.0 99.20 By fan
63 110 132 160 80 150 165 200 IP-00 QC2QDP 45.0 99.20 By fan
315 90 160 200 - 378 110 200 220 - IP-00 QC1RDP 55.0 121.3 By fan
90 160 200 220 110 200 220 250 IP-00 QC2RDP 55.0 121.3 By fan
370 110 200 220 - 444 132 220 250 - IP-00 QC1SDP 55.0 121.3 By fan
110 200 220 250 132 220 250 315 IP-00 QC2SDP 55.0 121.3 By fan
475 150 250 250 - 570 160 300 355 - IP-00 QC1TDP 80.0 176.4 By fan
150 250 250 335 160 300 355 400 IP-00 QC2TDP 80.0 176.4 By fan
610 200 315 400 - 732 220 400 450 - IP-00 QC1UDP 105.0 231.5 By fan
200 315 400 400 220 400 450 500 IP-00 QC2UDP 105.0 231.5 By fan
850 250 450 530 - 1020 300 560 600 - IP-00 QC1VDP 120.0 264.5 By fan
250 450 530 600 300 560 600 750 IP-00 QC2VDP 120.0 264.5 By fan
1075 355 600 670 - 1290 395 715 750 - IP-00 QC1XDP 150.0 330.7 By fan
355 600 670 750 395 715 750 850 IP-00 QC2XDP 150.0 330.7 By fan
2. Types and ratings
2-1
2-1. IEC Ratings (1)
Notes: (1) = Ratings in Amps. given for ambient temperature up to 40ªC and 1000m altitude
Derate output current by 1,5% / ºC above 40ºC.
Derate output current by 1% / 100m above 1000m
(2) = Heavy duty ratings, IEC Class 10 and 20 protections allowed
(3) = Light duty ratings, only IEC Class 10 protection allowed.
(4) = Maximum recommended Motor Power for IEC Class 20 protection. Set ASTAT's parameters "N" and "o" accordingly
(5) = Maximum recommended Motor Power for IEC Class 10 protection. Set ASTAT's parameters "N" and "o" accordingly
