6. Appendix
24 1r Programmable relay 11-12-14 R/W 22-30 See programmable
relays functions in page 3-6
25 2r Programmable relay 23-24 R/W 20,22-30
26 3r Programmable relay 33-34 R/W 21-30
27 OC Overcurrent (%N ) R/W 0-50 0: OFF
28 oc Overcurrent time (sec) R/W 0-99
29 r Reverse slow speed R/W 0-3 0: OFF
1: ON
2: I3
3: I4
30 Y Retry attemps R/W 0-4
31 y Retry time (sec) R/W 1-99
32 UV Undervoltage (%U) R/W 0-50 0: OFF
33 uv Undervoltage time (sec) R/W 0-99
34 OV Overvoltage (%U) R/W 0-30 0: OFF
35 ov Overvoltage time (sec) R/W 0-99
36 UC Undercurrent (%N) R/W 0-99 0: OFF
37 uc Undercurrent time (sec) R/W 0-99
38 PF Power factor (%) R/- 00-99
39 U Nominal voltage (volt) R/W 100-500
40 V Line voltage (volt) R/-
41 w Power (KW*10) R/-
42 X Local/remote control 0-3 0: OFF
1: ON
2: I3
3: I4
43 D Linear ramp control R/W 0-3 0: OFF
1: ON
2: I3
3: I4
44 J Slow speed control R/W 0-2 0: OFF
1: I3
2: I4
45 j Slow speed type R/W 0-1 0: HI
1: LO
46 2a Secondary acceleration ramp time (sec) R/W 1-99
47 2d Secondary deceleration ramp time (sec) R/W 1-99
48 A Dual ramp selection R/W 0-3 0: OFF
1: ON
2: I3
3: I4
49 UF Unit frame R/W 0-16 0: not defined
1 to 16: F to X frames
50 E Elapsed time (hours) R/-
51 - internal use
52 Q Recall factory settings -/W 1
53 2T Secondary starting torque (%DOL torque) R/W 10-90
54 m Current calibration R/-
55 - internal use
56 z Bypass function R/W 0-3 0: OFF
1: ON
2: I3
3: I4
57 - internal use
58 f Service factor (%N) R/W 100-130
59 t Voltage calibration R/-
60 RUN/STOP RUN/STOP order -/W 0: RUN
1: STOP
61 - internal use
62 - internal use
63 - internal use
64 - internal use
Parameter Parameter Function Read/Write Range Comments
number name (R/W)
6-10
