107 • Appendix B - Profibus
Parameter # Range Default
Thermistor Type 66 0 / 1 (0 - PTC, 1 - NTC) 0 (PTC)
Thermistor Trip 67 0..100 Tenth Kohm 0.1..10 K 0 (Off)
Undercurrent RST 68 10..120 (&121=OFF) 121 (Off)
Reserved 69..71
I/O Settings
Prog. Input #7 72 0..2(0=En.Save,1=S.Spd,2=Rst) 0 (Energy
Saver)
Prog. Input #8 73 0..2(0=D.Adj.,1=Rvrs,2=Rst) 0 (Dual Adjust)
Prog. Fault Relay 74 0..1 (0=Fault, 1=Fault-Fail Safe) 0 (Fault)
Relay ON Delay 75 0..3600 0 (Seconds)
Realy OFF Delay 76 0..3600 0 (Seconds)
Analog Output 77 0- Current, 0..200% of motor FLA 0 (Current)
Reserved 78
Communication Parameters
COMM. Protocol 80 0 – Modbus, 1-Profibus 1 - Profibus
Baud Rate 81 12..96 (*100) 96 (9600 bps)
Parity Check 82 0/1/2 (Even / Odd / No) 0 (Even)
Station Number 83 1..247 & (248= Off) 248 (Off)
1..126 & (127= Off) for Profibus
S. Link Par. Set 84 0 (Disable), 1 (Enable) 0 (Disable)
S. Link Control 85 0 (Disable), 1 (Enable) 0 (Disable)
Reserved 86..88
Modbus_#_Array 89..108 (# of parameter)
Defaults # are:
1 - Logic Status, 2 - I, 3 - V, 5 - Control In, 11 –
Thermistor Resistance, 37 - Thermal Capacity, 10 -
frequency, 4 - Phase Sequence, 6 - Dip Switch, 18
- Total Run Time, 19 - Total Starts, 20 - Last Start
Period, 21 - Last Start Peak I, 22 - time to start, 23
- Total Trips, 24 - last trip Number, 25 - Pre Trip I,
26 - Time to Reset U/C, 39 - Spare, 40 – Spare
