GE ASTAT XT QT 0008U Series User Manual

121 • Appendix C - DeviceNet™ to Modbus™ Gateway
C.16.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
C.17. I/O Settings Object (77
HEX –
1 Instance)
C.17.1. Class Attributes (Instance 0)
Attribute
ID
Name DeviceNet
Data Type
Data Value Access
Rule
1 Revision UINT 1 Get
C.17.2. Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 Prog. Input #7 0-2 0 Get/Set 40073
2 Prog. Input #8 0-2 0 Get/Set 40074
3 Prog. Fault Relay 0-1 0 Get/Set 40075
4 Relay ON Delay 0-3600 0 Get/Set 40076
5 Realy OFF Delay 0-3600 0 Get/Set 40077
6 Analog Output 0-200% of
Motor_Im
0 Get/Set 40078
7 Reserved Get/Set 40079
C.17.3. Common Services
Implemented for
Service
Code
Class Level Instance Level
Service Name
0E
HEX
Yes Yes Get Attribute Single
10
HEX
No Yes Set Attribute Single
C.18. Communication Parameter Object (78
HEX –
1 Instance)
C.18.1. Class Attributes (Instance 0)
Attribute ID Name DeviceNet
Data Type
Data Value Access
Rule
1 Revision UINT 1 Get
C.18.2. Instance Attributes (Instance 1)
Attribute
ID
Name Range Default
Value
Access
Rule
Modbus
Address
1 COMM. Protocol 0-2 2 Get 40081
2 Baud Rate 12-96 (*100) 9600 Get 40082
3 Parity Check 0-2 0 Get 40083
4 Station Number 1-247 & 248
1-126 &127
(Profibus)
248 Get 40084
5 S. Link Par. Set 0-1 0 Get/Set 40085
6 S. Link Control 0-1 0 Get/Set 40086
7-9 Reserved Get/Set 40087-89
10-29 Modbus_#_Array Get/Set 40090-
40109
