GE ASTAT XT QT 0008U Series User Manual

25 • Control Keypad
Only in Max. Mode
16
Slow SP & Saving
Parameters
Only in Max. Mode
16
Fault Settings
- **** -
Only in Max. Mode
16
I/O Settings
Parameters
Only in Max. Mode
16
COMM. Parameters
- **** -
Statistical Data
- **** -
Function & Default Function & Default Function & Default Function & Default Function & Default
Energy Saving
0 (MIN)
Phase Loss
Enabled
PROG. Input #7
Reset
COMM. Protocol
Modbus
Last Start Time
No Data
Slow Speed TRQ.
8
Phase Sequence
Disabled
PROG. Input #8
Dual Settings
Baud Rate
9600 (MODBUS)
Last Start Curr.
No Data
Max Slow SP Time
30 SEC.
Auto Reset
Disabled
PROG. Fault Relay
At Fault Close
Parity Check
EVEN
Elapsed Run Time
0 Hours
Store Settings
Slow SP & Saving
Thermistor Type
PTC
Relay ON Delay
0 SEC.
Station Number.
OFF
Number Of Starts
0
Thermistor Trip
Disabled
Relay OFF Delay
0 SEC.
S. Link Par. Set
DISABLED
Last Fault
No Data
Undercurrent RST
Disabled
Analog Output
I, 0...200% OF Im
Ser. Link Control
DISABLE
Motor FLT Current
0 % of Im
Store Settings
Fault Settings
Store Settings
I/O Settings
Store Settings
COMM. Parameters
Fault Counter
0
Previous Fault -1
No Data
COMM. Protocol
Profibus
PREVIOUS Fault -9
No Data
Baud Rate
AUTO (Profibus)
Parity Check
AUTO (Profibus)
PROFI. Network ID
OFF
S. Link Par. Set
Disabled
Ser. Link Control
Disabled
Store Settings
COMM. Parameters
COMM. Protocol
DeviceNet
Baud Rate
Set Manually
Parity Check
AUTO (DeviceNet)
DeviceNet ID
Set Manually
S. Link Par. Set
Disabled
Ser. Link Control
Disabled
Store Settings
COMM. Parameters
Note: There are three different groups of COMM. Protocol parameters. Each group of COMM. Protocol parameters
are only valid when its corresponding optional PCB is installed.
Appears when in
Test/Maintenance
Test/Maintenance
***Statistics***
Display and default
values
Auto Test
Press UP Key
Firmware Version
STRT-GE-270508
Store Settings
Default Data
Reset Statistics
Calibration VOLT
0 VOLT
Calibration CURR
5% of Ir
