Revision C 170 Series Monitor 7-31
2000947-004
Serviceable Assemblies: Nautilus Ultrasound Transducer Top Cover Replacement
Procedure
1. Turn off the monitor.
2. Unplug the transducer from the monitor.
3. Use the screw cap extraction tool to pry off the five screw caps (Refer to Figure
7-5). Discard all caps.
CAUTION
HANDLING—Take care not to damage the transducer base
sealing groove.
4. Remove the five sealing screws and discard.
5. Remove the transducer cover and flat-seal o-ring. Discard both items.
6. Follow the instructions for “Nautilus Transducer Reassembly” on page 7-32.
