CHAPTER 5: SETTINGS PRODUCT SETUP
D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL 5-51
5
Table 5-9: Port and protocol combinations
5.3.5.10 DNP protocol
SETTINGS  PRODUCT SETUP  COMMUNICATIONS  DNP PROTOCOL
PROTOCOL
setting
DNP CHANNEL 1(2) PORT
settings
RS232 RS485 Ethernet
DNP Channel 1: Eth TCP
Channel 2: Eth TCP
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: none
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: none
Channel 2: Eth TCP
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: none
Modbus Modbus DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: RS485
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: Eth TCP
Channel 2: RS232
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: RS485
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: Eth UDP
Channel 2: RS232
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: RS485
Channel 2: Eth TCP
Modbus DNP DNP, Modbus, IEC 61850
Channel 1: RS232
Channel 2: Eth TCP
DNP Modbus DNP, Modbus, IEC 61850
Channel 1: RS485
Channel 2: RS232
DNP DNP Modbus, IEC 61850
Channel 1: RS232
Channel 2: RS485
DNP DNP Modbus, IEC 61850
Channel 1: RS485
Channel 2: none
Modbus DNP Modbus, IEC 61850
IEC 104 Modbus Modbus IEC 104, Modbus, IEC 61850
IEC 103 Modbus IEC 103 Modbus, IEC 61850
 DNP PROTOCOL


 DNP CHANNELS

See below

DNP ADDRESS:
1
Range: 0 to 65535 in steps of 1

 DNP NETWORK
 CLIENT ADDRESSES
See below

DNP TCP/UDP PORT
NUMBER(20000): 20000
Range: 0 to 65535 in steps of 1

DNP UNSOL RESPONSE
FUNCTION: Disabled
Range: Enabled, Disabled

DNP UNSOL RESPONSE
TIMEOUT: 5 s
Range: 0 to 60 s in steps of 1

DNP UNSOL RESPONSE
MAX RETRIES: 10
Range: 1 to 255 in steps of 1

DNP UNSOL RESPONSE
DEST ADDRESS: 1
Range: 0 to 65519 in steps of 1

DNP CURRENT SCALE
FACTOR: 1
Range: 0.001, 0.01. 0.1, 1, 10, 100, 1000, 10000,
100000, 1000000, 10000000, 100000000
