6-16 D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL

METERING CHAPTER 6: ACTUAL VALUES

6.4.2 Sources

6.4.2.1 Menu

ACTUAL VALUES  METERING  SOURCE SRC 1

This menu displays the metered values available for each source.

Metered values presented for each source depend on the phase and auxiliary VTs and phase and ground CTs assignments

for this particular source. For example, if no phase VT is assigned to this source, then any voltage, energy, and power

values are unavailable.

6.4.2.2 Phase current metering

ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE CURRENT

 SOURCE SRC 1





 PHASE CURRENT

 SRC 1

See below



 GROUND CURRENT

 SRC 1

See page 6-17



 PHASE VOLTAGE

 SRC 1

See page 6-17



 AUXILIARY VOLTAGE

 SRC 1

See page 6-18



 POWER

 SRC 1

See page 6-18



 FREQUENCY

 SRC 1

See page 6-19

 PHASE CURRENT

 SRC 1



SRC 1 RMS Ia: 0.000

b: 0.000 c: 0.000 A



SRC 1 RMS Ia:

0.000 A



SRC 1 RMS Ib:

0.000 A



SRC 1 RMS Ic:

0.000 A



SRC 1 RMS In:

0.000 A



SRC 1 PHASOR Ia:

0.000 A 0.0°



SRC 1 PHASOR Ib:

0.000 A 0.0°



SRC 1 PHASOR Ic:

0.000 A 0.0°



SRC 1 PHASOR In:

0.000 A 0.0°



SRC 1 ZERO SEQ I0:

0.000 A 0.0°



SRC 1 POS SEQ I1:

0.000 A 0.0°



SRC 1 NEG SEQ I2:

0.000 A 0.0°
