5-210 D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL
GROUPED ELEMENTS CHAPTER 5: SETTINGS
5
The power swing detect element provides both power swing blocking and out-of-step tripping functions. The element
measures the positive-sequence apparent impedance and traces its locus with respect to either two or three user-
selectable operating characteristic boundaries. Upon detecting appropriate timing relations, the blocking and/or tripping
indications are given through FlexLogic operands. The element incorporates an adaptive disturbance detector. This

POWER SWING QUAD REV
REACH MID: 60.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING QUAD REV
REACH OUT: 70.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING REV
RCA: 75°
Range: 40 to 90° in steps of 1

POWER SWING OUTER
LIMIT ANGLE: 120°
Range: 40 to 140° in steps of 1

POWER SWING MIDDLE
LIMIT ANGLE: 90°
Range: 40 to 140° in steps of 1

POWER SWING INNER
LIMIT ANGLE: 60°
Range: 40 to 140° in steps of 1

POWER SWING OUTER
RGT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING OUTER
LFT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING MIDDLE
RGT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING MIDDLE
LFT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING INNER
RGT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING INNER
LFT BLD: 100.00 Ω
Range: 0.10 to 500.00 ohms in steps of 0.01

POWER SWING PICKUP
DELAY 1: 0.030 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING RESET
DELAY 1: 0.050 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING PICKUP
DELAY 2: 0.017 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING PICKUP
DELAY 3: 0.009 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING PICKUP
DELAY 4: 0.017 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING SEAL-IN
DELAY: 0.400 s
Range: 0.000 to 65.535 s in steps of 0.001

POWER SWING TRIP
MODE: Delayed
Range: Early, Delayed

POWER SWING BLK:
Off
Range: FlexLogic operand

POWER SWING
TARGET: Self-reset
Range: Self-reset, Latched, Disabled

POWER SWING
EVENTS: Disabled
Range: Disabled, Enabled
