2-34 D30 LINE DISTANCE PROTECTION SYSTEM – INSTRUCTION MANUAL
SPECIFICATIONS CHAPTER 2: PRODUCT DESCRIPTION
2
The following specifications apply to filter interface modules implemented before January 2012.
TYPICAL LINK DISTANCE
CONNECTOR LOSSES (Total of both ends)
ST connector: 0.7 dB (each)
FIBER LOSSES
820 nm multimode: 3 dB/km
1300 nm, Multimode 62.5/125 μm -16 dBm -32 dBm 16 dBm -8 dBm
50/125 μm -20 dBm 12 dBm
1300 nm, Single
mode
9/125 μm -15 dBm -32 dBm 17 dBm -8 dBm
1300 nm Laser,
Single mode
9/125 μm 0 dBm -34 dBm 34 dBm -8 dBm
1550 nm Laser,
Single mode
9/125 μm 5 dBm -34 dBm 39 dBm -10 dBm
Emitter, fiber type Transmit
power
Received
sensitivity
Power budget Maximum optical
input power
820 nm LED, Multimode –20 dBm –30 dBm 10 dB –7.6 dBm
1300 nm LED, Multimode –21 dBm –30 dBm 9 dB –11 dBm
1300 nm ELED, Single mode –23 dBm –32 dBm 9 dB –14 dBm
1300 nm Laser, Single mode –1 dBm –30 dBm 29 dB –14 dBm
1550 nm Laser, Single mode +5 dBm –30 dBm 35 dB –14 dBm
The power budgets are calculated from the manufacturer’s worst-case transmitter power and worst case receiver
sensitivity.
The power budgets for the 1300 nm ELED are calculated from the manufacturer's transmitter power and receiver
sensitivity at ambient temperature. At extreme temperatures these values deviate based on component tolerance.
On average, the output power decreases as the temperature is increased by a factor of 1 dB / 5 °C.
Emitter, fiber type Cable type Connector
type
Typical distance
Before
January
2012
From
January
2012
820 nm LED,
multimode
62.5/125 μm ST 1.65 km 2 km
50/125 μm ST 1.65 km 2 km
1300 nm LED,
multimode
62.5/125 μm ST 4 km 5 km
50/125 μm ST 4 km 5 km
1300 nm ELED,
single mode
9/125 μm ST 11.4 km 20 km
1300 nm Laser,
single mode
9/125 μm ST 64 km 65 km
1550 nm Laser,
single mode
9/125 μm ST 105 km 125 km
Typical distances listed are based on the following assumptions for system loss. As actual losses vary from one
installation to another, the distance covered by your system can vary.
Emitter, fiber type Cable type Transmit power Received
sensitivity
Power budget Maximum
optical input
power
